The PumpS SM borehole pump is the perfect solution for demanding applications that require high performance and long-term reliability. Made from high-quality stainless steel AISI 304, these pumps are designed for trouble-free operation in extreme conditions, offering maximum performance with minimal maintenance.
The PumpS SM pumps are equipped with floating impellers made from Noryl, which allow them to pump water with a sand content of up to 150 g/m3. This makes them ideal for harsh environments such as industrial and agricultural applications. All critical components, including shaft coupling, shaft, discharge casing, suction strainer, and pump housing, are made from high-quality stainless steel AISI 304, ensuring long-term resistance to corrosion and wear.
The hydraulic flange is manufactured according to NEMA standards, ensuring compatibility and easy installation in various applications.
F.B. Submersible Motor - Maintenance-Free and Efficient
The submersible pump is powered by a motor from the renowned Italian company F.B. Submersible Motors, which guarantees high quality and maintenance-free operation throughout the pump’s lifespan. The motors feature Class F insulation and are water-cooled, filled with oil that is harmless to the environment.
Performance and Reliability
This pump is built for demanding operational conditions in various fields, including industrial, agricultural, and large residential settings. The pump features a built-in non-return valve that prevents backflow, ensuring efficient and secure operation.
Technical Specifications:
• Pump Housing: Stainless steel AISI 304
• Motor Housing: Stainless steel AISI 304
• Suction, Discharge, and Strainer: Stainless steel AISI 304
• Impellers: Noryl (highly resistant to wear and corrosion)
• Built-in Non-return Valve: Directly integrated into the pump for efficient operation
• Motor Coupling: According to NEMA standards
• Motor: Asynchronous motor, water-cooled
• Motor Insulation: Class F
• Motor Protection: IP 68 (fully submersible and dustproof)
Benefits of Using the PumpS SM:
1. Long-Term Reliability: High-quality materials and design ensure long-term trouble-free operation, even in the most demanding environments.
2. High Performance: Capable of pumping water with up to 150 g/m3 of sand, making it suitable for industrial and agricultural applications.
3. Maintenance-Free Operation: The water-cooled motor requires no special maintenance, reducing costs and increasing efficiency.
4. High-Quality Materials: Stainless steel AISI 304 components ensure resistance to corrosion and extend the pump’s lifespan.
Applications:
The Bakalar-PumpS SM borehole pump is ideal for applications where high performance and durability are needed. Key areas of use include:
• Industrial Applications: Water pumping in demanding conditions with high sand or impurity content.
• Agricultural Use: Irrigation systems and water pumping from wells.
• Large Residential Buildings: Water supply for households or garden irrigation.
